| Brand Name: | Ankuai Intelligent Tech Inc. |
| Model Number: | AKD908 |
| MOQ: | 1 Set |
| Price: | Negotiable |
| Packaging Details: | Regular package way with carton |
| Payment Terms: | T/T |
Features
●No position sensor, accurate stop. A Pair is also fully synchronized
●No anti-shock rubber, no impact, no bounce, free adjustment.
●No clutch device, boom will auto-rise when power is off (or unlock when power is off, only use your hand to lift the boom gently.
●Highly reliable industrial-grade sports parts, surpass the industry quality.
●Motor cooling fan, solve the problem of heat protection.
●Traffic light, red and green traffic lights can be added to enhance safety further.
●Panel with LED indicator red and green light.
|
Voltage |
DC24V |
|---|---|
| Drive | DC serovo motor |
| Motor Power Consumption | 100W |
| Cabinet Dimension | 350*290*1020mm |
| Working Temperature | -30°C ~80°C |
| Humidity | ≤90% |
| Boom Length | ≤3m |
| Open/Close Time | 0.6~0.9 |
| The Height of Boom Support | 890mm |
| Remote Control Distance | ≤30m |
| IP | IP54 |
| Input Interface | +12V relay signal or ≤100MS pulse signal |
| Remote Control Frequency | 60HZ |
● Direction is adjustable.
● Intelligent limited sensor. Limited sensors can check open & close positions automatically. No need adjust it by hand.
Our Company
1. What is your company's strength in this field?
We are one of the greatest head leaders in this field. We are an ISO-approved factory, taking place in an area of over 50,000 square meters, with 130+ national patents. We have a strong R&D team with 30+ professional R&D staff and over 300 well-trained assembly workers. So far, we have 76 distributors and multiple sup companies in China and more than 50 distributors all around the world.
2. How do you guarantee the quality of your product/quality control?
We have ISO9001 and CE certificates among our products, all details can be found on our website. We commit to providing the best product quality possible to our customers.
3. Do you provide OEM service?
Yes, we can offer OEM services as follows:
1) We can customize the barrier gate according to your needs.
2) We can print your logo on the barrier gate, and customize retail box packing and other things you need.
4. Lead time for standard item
1-50 sets: 5 working days; 50-100 sets: 7 working days; 100-500sets: 15 working days. For custom-made packages or logos, 3-10 working days longer
5. Do you provide quality guarantee/warranty and after-sales service?
We have 1-year quality guarantee. Our well-trained and passionate sales and professional engineers can provide you with timely help.
6. What are your after-sale services?
1) For all your inquiries, the response can be made within 24 hours.
2) Our company is equipped with excellent engineers and sales. We can provide you with first-quality products and the best price.
3) Our experienced engineers can guide you about how to use our products. Call our after-sales team at any time.
|
