| Brand Name: | AnKuai |
| Model Number: | AK-RB101 |
| MOQ: | 1 SET |
| Price: | Negotiable |
| Packaging Details: | Wooden case will be extra cost and suggested. |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
Foundation
Trenching: Length: (length of Road blocker + 0.4) m,
Width: 1.4 m
Depth:(0.76 + panel thickness + 0.2) m
Reservoir tank based on local situation (or connected with city drainage pipe)
Use C30+ leve/ concrete to make a 200 mm cushion and bury PVC drain pipe in it.
|
Control System
|
Electro- Hydraulic
|
|
System Dynamic power
|
3.75KW
|
|
Rise time :
|
≤1-3S(adjustable)
|
|
fall time :
|
≤1-3S (adjustable)
|
|
Buffer function
|
buffer time :0.2s-0.5s
|
|
Running noise
|
≤60 db
|
|
Voltage:
|
Three-phases 380V,(control voltage 24V)
|
|
Oil container:
|
60liter
|
|
Control solenoid valve
|
24V
|
|
Lifting solenoid valve
|
24V
|
|
Remote control distance
|
Approx .50-100m
|
|
Working Temperature :
|
-35ºC~75ºC(suitable)
|
|
Material:
|
304 stainless steel ,Spray anti-rust paint
|
|
Material thickness
|
16mm,20 mm,25 mm (Optional)
|
|
Waterproof:
|
IP68, double sealed
|
|
LED light color
|
red,blue,green,yellow,purple,white…(customized)
|
|
Color:
|
red,blue,green,yellow…(can be customized)
|
|
Weight:
|
1.5T
|
|
