| Brand Name: | AnKuai |
| Model Number: | AK-RB101 |
| MOQ: | 1 SET |
| Price: | Negotiable |
| Packaging Details: | Wooden case will be extra cost and suggested. |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
2. Installation
·Extended wire and Tube:
0.3 m^2 four-core cable line (for LED light).
Hydraulic tube (Length is based on the PVC tube and should be long enoughto connect the hydraulic station).
Electromagnetic valve wire setup (Lifting 1&2 input, Falling 1&2 input).
Get the main body into the pit.
Cable wire and hydraulic tube are connected to ground through the PVC pipe.
Use PVC pipe to connect the drainage pipe to guide the drainage process.
|
Control System
|
Electro- Hydraulic
|
|
Passing pressure:
|
≤120 tons container trucks
|
|
System Dynamic power
|
3.75KW
|
|
Rise time :
|
≤1-3S(adjustable)
|
|
fall time :
|
≤1-3S (adjustable)
|
|
Buffer function
|
buffer time :0.2s-0.5s
|
|
Running noise
|
≤60 db
|
|
Voltage:
|
Three-phases 380V,(control voltage 24V)
|
|
Oil container:
|
60liter
|
|
Control solenoid valve
|
24V
|
|
Lifting solenoid valve
|
24V
|
|
Remote control distance
|
Approx .50-100m
|
|
Working Temperature :
|
-35ºC~75ºC(suitable)
|
|
Material:
|
304 stainless steel ,Spray anti-rust paint
|
|
Material thickness
|
16mm,20 mm,25 mm (Optional)
|
|
Waterproof:
|
IP68, double sealed
|
|
Color:
|
red,blue,green,yellow…(can be customized)
|
|
Weight:
|
1.5T
|
|
