AC 220V 110V Swing Barrier Turnstile Speed Automatic Turnstile Gate For Entry

AC 220V 110V Swing Barrier Turnstile Speed Automatic Turnstile Gate For Entry

  • AC 220V 110V Swing Barrier Turnstile Speed Automatic Turnstile Gate For Entry
  • AC 220V 110V Swing Barrier Turnstile Speed Automatic Turnstile Gate For Entry
  • AC 220V 110V Swing Barrier Turnstile Speed Automatic Turnstile Gate For Entry
AC 220V 110V Swing Barrier Turnstile Speed Automatic Turnstile Gate For Entry
Product Details:
Place of Origin: China
Brand Name: ANKUAI
Certification: CE, ISO
Model Number: AKT326
Payment & Shipping Terms:
Minimum Order Quantity: 1 peice
Price: USD 308-350 /Peice
Packaging Details: 1260×220x1040mm
Delivery Time: 3-5 working days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 10000 Peices/Month
Contact Now
Detailed Product Description
Product Name: Swing Barrier Gate Size: 1200x150x980mm
Passage Width: 600mm(Customized) Power Supply: AC 220V/110V
Material: SUS304 Hairline 400# MCBF: 5,000,000 Cycles
Communicate: RS485,Dry Contact Arm Turning: Uni Or Bi-direction
Lead Time: 3-5 Working Days Price: Negotiate
High Light:

110V Swing Barrier Turnstile

,

220V Swing Barrier Turnstile

,

Bi-direction Automatic Turnstile Gate

AC 220V 110V Swing Barrier Turnstile Speed Automatic Turnstile Gate For Entry 0

Model Number AKT326
Power Supply AC220V ± 10%
Power Consumption 40W/24V
Motor DC24V Brushless Motor
MCBF 5,000,000 Cycles
Passage Width 600mm(Customized)
Passing Speed 30 People/Minute
Communication Interface RS485 (Distance: <=1200m)
Direction Bi/Uni-direction
Humidity <95%
Material 304 SUS Hairline
Dimension 1200x150x980mm



Description:

ANKUAI offers a selection of standard rotating-arm tripod, half-height, and full-height turnstiles.swing barrier turnstile. A state of the art ‘optical turnstile’, which replaces the need for an obtrusive physical barrier by utilising active infra-red beams to create an invisible electronic field between two pedestals, monitoring the passage of every individual entering and leaving a facility. They activate an alarm in the event of an illegal action. If an unauthorised person attempts to enter, the optical turnstile is designed to detect tailgating, collusion, non-entry and obstruction.



Features:

1. Problem-self-checking function.
2. Many options of working ways: Bi-direction card reading; One direction card reading and another no reading; One direction card reading and another freely. And single direction photocell controlled passing and close. Working ways can be set in the control panel.
3. When power off, arm open automatically and power on again, arm will be held automatically.
4. When valid card read and passenger passed, arm can be delayed to close from 1-60s which can be set in the control panel.



AC 220V 110V Swing Barrier Turnstile Speed Automatic Turnstile Gate For Entry 1

AC 220V 110V Swing Barrier Turnstile Speed Automatic Turnstile Gate For Entry 2AC 220V 110V Swing Barrier Turnstile Speed Automatic Turnstile Gate For Entry 3AC 220V 110V Swing Barrier Turnstile Speed Automatic Turnstile Gate For Entry 4AC 220V 110V Swing Barrier Turnstile Speed Automatic Turnstile Gate For Entry 5AC 220V 110V Swing Barrier Turnstile Speed Automatic Turnstile Gate For Entry 6

  1. AC 220V 110V Swing Barrier Turnstile Speed Automatic Turnstile Gate For Entry 7AC 220V 110V Swing Barrier Turnstile Speed Automatic Turnstile Gate For Entry 8AC 220V 110V Swing Barrier Turnstile Speed Automatic Turnstile Gate For Entry 9AC 220V 110V Swing Barrier Turnstile Speed Automatic Turnstile Gate For Entry 10
