Ten years of craftsmanship, a hundred years of promise.
 |
| Place of Origin: | China |
| Brand Name: | ANKUAI |
| Certification: | CE, ISO |
| Model Number: | AKT321 |
| Minimum Order Quantity: | 1 peice |
|---|---|
| Price: | USD 445-518 /Peice |
| Packaging Details: | 1400x180x1020mm |
| Delivery Time: | 3-5 working days |
| Payment Terms: | L/C, T/T, Western Union |
| Supply Ability: | 10000 Peices/Month |
| Product Name: | Swing Barrier Gate | Housing Size: | 1400x180x1020mm |
|---|---|---|---|
| Passage Width: | 600-1000mm | Drive Motor: | DC24V Brushless 60W |
| Material: | 304 Stainless Steel Or 316 Stainless Steel | MCBF: | 5 Millions Cycles |
| Passing Speed: | ≥30 People/minute | Arm Turning: | Bi-direction |
| Color: | Customized Color | MOQ: | 1 Pc |
| High Light: | Auto Electric Swing Gate,Bi-direction Electric Swing Gate,60W Entrance Control System |
||
| Model Number | AKT321 |
| Power Supply | AC220V ± 10% |
| Power Consumption | 60W |
| Motor | DC24V Brushless Motor |
| MCBF | 5,000,000 Cycles |
| Passage Width | 600-1000mm |
| Operating Speed | 1S |
| Communication Interface | RS485, Dry Contact, TTL232 |
| Direction | Bi/Uni-direction |
| Humidity | ＜95% |
| Material | SUS304 Hairline |
| Dimension | 1400x180x1020mm |
(1) Swing turnstile gate has automatic return function: After the passage process is completed, the brake wings automatically return to the initial blocking position.
(2) Power-off and opening function of automatic swing turnstille: When the power is off, the system will automatically open the brake wings to open, which is convenient for evacuation of the crowd and meets fire protection requirements.
(3) Automatic swing gate turnstile has anti-illegal intrusion function: When the card is invalid, there is no card swiping, or the passage is forbidden, the forcible entry into the channel will be regarded as illegal intrusion, and the system will automatically alarm and close the flap.
(4) Anti-reverse intrusion function: Before the end of the passage process in a certain direction, pedestrians entering the passage from the opposite direction will be regarded as reverse intrusion, the system will automatically alarm and close the wing.
(5) Anti-trailing function: The photoelectric switch detects the pedestrian traffic situation, and detects the following phenomenon (the people behind are close to the person in front, intending to pass without swiping the card), the system will automatically alarm and close the brake wings.
(6) Intelligent linkage alarm: including illegal intrusion, reverse traffic and other alarms, which can be linked with other alarm monitoring equipment and can be heard.
(7) Anti-pinching and anti-collision function:
Infrared anti-pinch: Install multiple pairs of photoelectric switches near the area where the wing is active (anti-pinch area). Once a person or object is detected in the anti-pinch area, the wing automatically stops; The flaps continued to move.
(8) Intergration
Our Turnstile can combine with different kinds of access readers,like: RFID Reader&Fingerprint Reader &Coin Machine&Barcode System&ESD Tester Access Control(If you have access control system,you can only purchase our turnstiles,if not, our side will install the access control system for you),except acess system,also can use remote(this is free gift to you).
